ACEY-AS11S Battery sorter can automatically sort the batteries according to the specified requirements, and has the characteristics of rapid and accurate sorting. Auto sorting machine fundamentally avoids unreliable factors such as human misoperation and misclassification in the battery sorting process, and improves the quality and efficiency of battery sorting.
Brand:
ACEYItem No.:
ACEY-AS11SCompliance:
CE CertifiedWarranty:
One Year warranty with lifetime supportOrder(Moq):
1setProduct Origin:
ChinaLead Time:
7days
11 Channel 18650-32700 Lithium Battery Cell Sorting Machine For Cylindrical Cell
Description
The equipment is controlled by PLC and PC. The PLC is responsible for battery feeding, battery handling and battery sorting. The PC is responsible for battery testing data collection, voltage internal resistance rating, high work efficiency, good product performance. The device is equipped with universal movable casters, the device can easily move when it is displaced.
Features
1. 18650/21700/26650/32650/32700 li-ion batteries test & sorting machine
2.High precision and fast speed,can test about 5000pcs batteries per hour.
3. Touch screen operation, easy and fast responding.
4. Customers can set the voltage and internal resistance by themselves.
Specification
Model No. |
ACEY-AS11S |
Voltage Supply |
single-phase ~220V±10%/50Hz±10%, power <800W
|
Battery Types |
18650(other sizes available) |
Receiving channel |
10 sorting & matching group channels, 1 unqualified product channel, available arbitrary set for each channel's sorting value. |
Test parameters |
AC internal resistance, DC voltage |
Internal resistance test |
Test range: 80mΩ, |
Accuracy: ±0.5%rdg |
|
Display resolution: 0.01mΩ |
|
Voltage test |
Test range: 8V |
Accuracy :±0.015%rdg, |
|
Display resolution: 0.01mV |
|
Sorting speed |
80ppm |
AI.Set function |
Intelligent one-button setting, specially designed for new functions of battery pack. |
Size |
L1430mm*W660mm*H1350mm |
Weight |
<200Kg |
